Laser Application Field In Distance Measurement

This article provides a comprehensive exploration of laser ranging technology, tracing its historical evolution, elucidating its core principles, and highlighting its diverse applications. Intended for laser engineers, R&D teams, and optical academia, this piece offers a blend of historical context and modern understanding.

The Genesis and Evolution of Laser Ranging

Originating in the early 1960s, the first laser rangefinders were primarily developed for military purposes [1]. Over the years, the technology has evolved and expanded its footprint across various sectors, including construction, topography, aerospace [2], and beyond.


Laser technology is a non-contact industrial measurement technique that offers several advantages when compared to traditional contact-based ranging methods:

- Eliminates the need for physical contact with the measuring surface, preventing deformations that can lead to measurement errors.
- Minimizes wear and tear on the measurement surface since it doesn't involve physical contact during measurement.
- Suitable for use in special environments where conventional measurement tools are impractical.

Principles of Laser Ranging:

Laser ranging utilizes three primary methods: laser pulse ranging, laser phase ranging, and laser triangulation ranging. Each method is associated with specific commonly used measuring ranges and levels of accuracy.

Laser Pulse Ranging

Primarily employed for long-distance measurements, typically exceeding kilometer-level distances, with lower accuracy, typically at the meter level.

Laser Phase Ranging:

Ideal for medium- to long-distance measurements, commonly used within ranges of 50 meters to 150 meters.

Laser Triangulation:

Mainly used for short-distance measurements, typically within 2 meters, offering high accuracy at the micron level, although it has limited measurement distances.

DALL·E 2023-10-30 14.54.02 - 8k HD super view photograph of a man of Hispanic descent in a forest setting, illuminated by natural sunlight breaking through the trees. He is holdin

Applications and Advantages

Laser ranging has found its niche in various industries:

Construction: Site measurements, topographical mapping, and structural analysis.
Automotive: Enhancing advanced driver assistance systems (ADAS).
Aerospace: Terrain mapping and obstacle detection.
Mining: Tunnel depth assessment and mineral exploration.
Forestry: Tree height calculation and forest density analysis.
Manufacturing: Precision in machinery and equipment alignment.

The technology offers several advantages over traditional methods, including non-contact measurements, reduced wear and tear, and unmatched versatility.

Lumispot Tech's solutions in the Laser Ranging Field


Erbium-Doped Glass Laser (Er Glass Laser)

Our Erbium-Doped Glass Laser, known as the 1535nm Eye-Safe Er Glass Laser, excels in eye-safe rangefinders. It offers reliable, cost-effective performance, emitting light absorbed by the cornea and crystalline eye structures, ensuring retina safety. In laser ranging and LIDAR, especially in outdoor settings requiring long-distance light transmission, this DPSS laser is essential. Unlike past products, it eliminates eye damage and blinding hazards. Our laser uses co-doped Er: Yb phosphate glass and a semiconductor laser pump source to produce a 1.5um wavelength, making it perfect for, Ranging, and Communications.



Laser ranging, particularly Time-of-Flight (TOF) ranging, is a method used to determine the distance between a laser source and a target. This principle is widely used in various applications, from simple distance measurements to complex 3D mapping. Let's create a diagram to illustrate the TOF laser ranging principle.
The basic steps in TOF laser ranging are:

TOF ranging principle diagram
Emission of Laser Pulse: A laser device emits a short pulse of light.
Travel to Target: The laser pulse travels through the air to the target.
Reflection from Target: The pulse hits the target and is reflected back.
Return to Source: The reflected pulse travels back to the laser device.
Detection: The laser device detects the returning laser pulse.
Time Measurement: The time taken for the round trip of the pulse is measured.
Distance Calculation: The distance to the target is calculated based on the speed of light and the measured time.


This year, Lumispot Tech has launched a product perfectly suited for application in the TOF LIDAR detection field, an 8-in-1 LiDAR light source. Click to learn more if you are interested


Laser Ranging Module

This product series primarily focuses on a human eye-safe laser ranging module developed based on the 1535nm erbium-doped glass lasers and 1570nm 20km Rangefinder Module, which are categorized as Class 1 eye-safety standard products. Within this series, you'll find laser rangefinder components from 2.5km to 20km with compact size, lightweight build, exceptional anti-interference properties, and efficient mass production capabilities. They are highly versatile, finding applications in laser ranging, LIDAR technology, and communication systems.
