    976nm (VBG) Fiber Coupled Diode Laser Featured Image
    • 976nm (VBG) Fiber Coupled Diode Laser

    Medical       Laser Dazzler
    Illumination       Detetcion       Research

    976nm (VBG) Fiber Coupled Diode Laser

    Wavelength: 976nm VBG (±0.5nm-1nm)

    Power Range: 25W -1000W

    Fiber Core Diameter: 105um, 200um, 220um

    Cooling: @25℃ water cooling (OEM 40℃)

    NA: 0.22

    NA(95%): 0.12-0.21

    Features: Small size, light weight, high power stability

    Defense Grade


    Product Detail

    Product Tags

    Specifications

    Product Name Wavelength Output Power Fiber Core Diameter Model Datasheet
    Multimode Fiber-Coupled Laser Diode 976nm 25W 105um LMF-976A-C25-F105-C3



    		 pdfDatasheet
    Multimode Fiber-Coupled Laser Diode 976nm 100W 105um LMF-976A-C100-F105-C18 pdfDatasheet
    Multimode Fiber-Coupled Laser Diode 976nm 140W 105um LMF-976A-C140-F105-C14C-A0001 pdfDatasheet
    Multimode Fiber-Coupled Laser Diode 976nm 240W 105um LMF-976D-C240-F105-C24-B pdfDatasheet
    Multimode Fiber-Coupled Laser Diode 976nm 360W 220um LMF-976A-C360-C24-B pdfDatasheet
    Multimode Fiber-Coupled  Laser Diode 976nm 510W 220um LMF-976A-C510-C24-B pdfDatasheet
    Multimode Fiber-Coupled Laser Diode 976nm 650W 200um LMF-976A-C650-F200-C32 pdfDatasheet
    Multimode Fiber-Coupled Laser Diode 976nm 650W 220um LMF-976A-C650-F220-C32 pdfDatasheet
    Multimode Fiber-Coupled  Laser Diode 976nm 1000W 220um LMF-976A-C1000-F220-C36 pdfDatasheet
    Note:

    Applications

    1.High-Energy Destruction

    Lumispot’s developed fiber-coupled semiconductor diode laser serves as the pump source for high power laser.

    app201

    2.1064nm Fiber Laser Applications

    Metal cutting/welding, cladding, brazing, additive manufacturing (DED/L-PBF)

    app202
